Description
Standard features include:
- Column is fabricated from one piece steel pipe and all exposed parts are recessed in welded steel plates
- Mounting plate comes standard
- Access plates are vandal resistant and provide easy maintenance
- Push button chrome plated brass valve recessed in 3/8” steel plate
- Steel bubbler guard(s) and chrome plated brass bubbler
- Adjustable flow regulation
- Heavy 3/8” sheet steel arm
- 18 gauge brush finished stainless steel receptor with a vandal resistant chrome plated brass drain plug
- Stainless steel supply fittings connected to reinforced tubing
- Blue powder coat finish with optional colors and stainless steel (-SS) available
- In-line mesh screen strainer
- 10-3/4″ diameter steel pipe(s) with 3/16″ wall thickness
- 6-5/8″ diameter steel pipe with 1/8″ wall thickness
- Delivers 8.0 GPH of chilled water refreshment
- Available in single, double or triple fountain styles
- Heavy duty, vandal resistant spray head(s)
- Timer controlled, low maintenance water control valve(s)
- Mist heads are made from heavy duty materials and are timer controlled
- Supply complete with 1/2” IPS lock shield screwdriver stop
- 1-1/4” IPS waste pipes included with every fountain
- Surface type with mounting plate welded to pedestal.
- Metering valve is standard.
- ADA Compliant
Dimensions
- 6650 – 80″H x 26-5/8″W x 6-5/8″Dia.
- All dimensions subject to manufacturing variance of plus or minus 1/4″ (6 mm)
